UHF Station Puxing PX-777

Overview

Puxing Electronic Science & Technology Co. Ltd. is a company that emerged in 1987, focusing on the development of communication equipment such as transceiver radios for domestic use, technical fields, and other areas requiring wireless communications. Today, Puxing products are shipped worldwide and are appreciated for their excellent quality-price ratio.

Description

Transceiver Station Puxing model PX-777. For those unfamiliar, we can say that this station features the following specifications:

• The operating frequencies of the station range from 400MHz to 470MHz, meaning it can be configured to communicate with classic PMR 446 stations.
• The transmission power of the station is quite high at 4W, allowing for signal transmission over relatively long distances.
• The battery is a Li-ion type with a capacity of 1200mAh. The device has a long autonomy.
• The sound clarity is good both during reception and transmission.
• The programming of the station is simple and intuitive.
• Up to 128 communication channels can be programmed.
• The station features a scanning function for preset channels or frequencies.
• The station allows for operation in 2 modes. One mode where the frequency is set manually and another mode where frequencies are memorized and noted as communication channels.
• The screen color can be one of three colors: Orange, Blue, and Purple.
• The keypad can be locked to prevent accidental access to the menu.

For those knowledgeable in the field of communications, we have the following specifications:

• ANI Encode
• Scrambler
• UHF working band
• Operating frequency 400 - 470MHz
• 128 positions for preset channels
• 50 CTCSS and 104 DCS
• VOX function
• Frequency scanning and CTCSS scanning
• 3 types of scanning TO/CO/SE
• Sound alarm
• Programmable via PC
• Transmission end confirmation sound
• Priority scanning function
• Adjustable transmission power High/Low
• Channel swapping I/VFO
• Squelch level 0 - 9
• Busy channel lock
• Frequency inversion function
• Frequency adjustment steps: 25k, 12.5k, 6.25k, 10k, 5k
• Ability to name channels
• Auto programming

The package includes the Puxing PX-777 transceiver station, a 1200mAh Li-ion battery, UHF antenna, charger (power supply + charging dock), and a user manual in English.
