Nimrod LiPo battery of crane X3 type composed of 3 cells resulting in 11.1V with a capacity of 1300 mAh. The battery discharge rate is approximately 25C, providing the necessary current for the replica in most cases.
Equipment Specifications
| Width | 3x 21 mm |
| Battery Type | Li-Po |
| Discharge | 25 C |
| Battery Shape | Crane |
| Voltage | 11.1 V |
| Magazine Capacity | 1300 mAh |
| Battery Connector | Small Tamiya |
| Length | 3x 130 mm |
Product Description
Presentation:
This Nimrod battery is of LiPo type and consists of 3 cells forming a crane X3 assembly. It has a voltage of 11.1V and a capacity of 1300mAh. The battery technology allows for very compact dimensions of the entire assembly, thus enabling installation in very tight battery compartments. The 25C discharge rate allows for optimal current supply for the replica's power needs.
The battery's insulation is well-made, and the wires and connectors are of high quality. This battery is equipped with a Tamiya Mini connector.
WARNING:
- Lithium Polymer (LiPo) batteries can be extremely dangerous.
- The user must ensure all safety precautions for: potential fire, bodily injury, and damage to property.
- In case of improper use, damage, or manufacturing defect, LiPo batteries can cause explosions, fire, smoke, and poisoning risks.
- By purchasing this type of battery, the user assumes responsibility for any risks associated with LiPo batteries.
- LiPo batteries are not toys and should not be left within reach of children as they can pose a real health hazard.
- LiPo batteries should not be thrown into fire, placed in an oven, or microwave as they may explode.
- LiPo batteries contain/can emit electrolytes, toxic vapors, and other harmful chemicals. Handle these batteries carefully and avoid, in any form, contact with skin, eyes, or other body parts. In case of contact, rinse thoroughly with water and contact a doctor immediately.
- Do not attempt to charge mechanically or chemically damaged batteries.
Actions that lead to battery damage:
- Charging LiPo batteries with a charger that does not balance and lacks automatic shut-off.
- Connecting in series or parallel with another cell or battery even if they appear similar.
- Exceeding maximum and minimum operating voltages.
- A drop or rise in temperature outside the permitted limits.
- Excessive charging current.
- Short-circuiting the battery terminals.
- Subjecting the battery to mechanical shocks such as dropping, hitting, bending, cutting, twisting, deforming, or puncturing.
- Contact with liquids.
- Improvising an improper charging setup.
- Using improper, improvised charging cables.
General information:
- LiPo batteries consist of cells.
- The parameters of this type of battery are: Voltage measured in Volts (V), Capacity measured in milliamp hours (mAh), and instantaneous discharge (C).
- Each LiPo battery has a power connector and a charging connector.
- The power connector is used to power the device intended for powering.
- The charging connector is exclusively for charging the battery. (in some cases, charging is done through both the power and charging connectors)
- Charging the battery is done using the charging connector, and for some advanced chargers, connecting the power connector is also necessary.
- LiPo batteries are charged with special chargers for LiPo batteries that have the function of balancing the voltage of each cell and automatic shut-off of charging.
- Each LiPo battery has a maximum charging rate of 1.05X the battery capacity, which must not be exceeded during charging.
- Each cell has a maximum voltage of 4.2V and a minimum voltage of 2.7V.
- During operation or charging, the battery temperature must not drop below 0°C or rise above 50°C.
- For long-term storage of the battery, the battery capacity should be between 15 and 25% of the maximum value.
Airsoft6 cannot guarantee that you have used correct operating methods and have adhered to the conditions for charging, discharging, or storing LiPo batteries. For this reason, we reserve the right to refuse the replacement, as a warranty, of incorrectly used batteries (which violate the above instructions and warnings) and are not responsible for material, moral damages, or loss of human life.
