GATE TITAN Advanced Mosfet Front Wiring

We are pleased to present one of the most advanced electronic control units for electric airsoft replicas. This control unit is called TITAN and is offered by GATE. It is designed to replace the mechanical contact of the replica, eliminating mechanical work and significantly improving the feedback control of the replica.

Due to the technology used, the characteristics of the replica can change completely, transforming your replica into a marvel of airsoft technology. The 20 functions of this device will provide numerous advantages, easily configurable through the control card or a direct connection to your PC.

The functions of this device are as follows:

Trigger sensitivity adjustment: This function is possible thanks to the optical sensors with which the TITAN unit is equipped. There are 5 optical sensors aligned at the trigger, allowing the use of the trigger starting from the first millimeter of movement and finishing with the last. By using optical sensors, the possibility of mechanical failure of the trigger contact is eliminated.

Multiple firing modes:

• Safe
• Semi
• Binary
• Burst
• Burst/Auto
• Auto

Automatic cycle detection: Thanks to the internal optical sensors, the TITAN control unit will know exactly when to stop the sector wheel, thus greatly improving the internal reliability of the replica.

Pre-cocking (Pre-cocking Gen.2): This function allows for systematic cocking of the spring, so that when the trigger is pulled, the response time is very short until the actual shot. Generation 2 includes "Smart precocking" which allows for automatic positioning of the piston based on how quickly the trigger is pulled.

Burst Gen. 2: This function allows you to fire a specific number of BBs with a pull of the trigger. From 2 BBs to 10 BBs. An important aspect when using low-cap or mid-cap magazines.

Rate of fire control: TITAN will allow us to control the rate of fire of the replica. This function allows for the provision of between 50% and 100% of the battery power to protect the replica when using overly powerful batteries.

First shot acceleration: When the rate of fire is low from the mosfet settings, we can opt for the first/first shots to have maximum power to significantly improve the trigger response.

Shot delay (Sniper delay): Similar to real weapons, TITAN will allow for a delay between shots of 0.5S and 3S to simulate recoil or the loading of a manual rifle.

Smart trigger: This function will allow us that when we electronically lower the rate of fire of the replica, the first shot still has maximum power, thus achieving an instant trigger response.

AUG mode: Similar to the AUG or P90 trigger, it is possible that in the first part of the trigger, the replica benefits from a certain type of fire and at the end from another type of fire. An important aspect when we do not want to waste time moving the selector position.

Battery protection: To prevent battery damage, TITAN will interrupt the operation of the replica when the voltage from the battery drops below the minimum safety value.

Low battery alarm: When the voltage from the battery drops towards the minimum value, the replica will alert us to this by vibrating the motor.

Electronic safety: The device is equipped with electronic safety against overload or short circuit. When an anomaly in current consumption is detected, the control unit will stop the power supply to the replica.

Mosfet: Above all other functions, at the core of this control unit is a highly capable mosfet that protects the internals of the replica from potential overload.

Test function: This function will allow us to find out if there is something wrong with the control unit and if so, where the problem is located.

Corrosion-resistant coating: This coating will allow us to keep the control unit functioning properly even when the weather conditions are unfavorable.

This device can operate with voltages between 3V and 17V DC.

In the package, you will find:

• Advanced V2 mosfet front wiring unit
• USB Link
• USB-C cable for USB Link
• Micro-USB cable for USB Link
• Installation kit
• Installation manual in English

WARNING:

The warranty is strictly provided for units installed in our service. The installation of this mosfet must be carried out by qualified or experienced personnel. The installation of this mosfet does not require modification of the mechanism casing, but the installation of the anti-reverse requires modification of the mechanism casing.
